DVB-T2 Receiver Terrestrial Receiver Support H. 265 IPTV Set Top Box


√Technical specification:
Product Type NameProduce Type NumberDVB-T2 H.265
Main FeaturesSTB TypeDVB-T2 FTA Receiver
Main ChipsetSunplus1509M
Mechanical115MM/148MM/168MM/220MM/260MM
TUNER TypeMXL608 & R836
SMPS TypeSeparate SMPS
Function/InterfaceCVBS,AR,AL,YPbPr,SPDIF,HDMI, 1*USB2.0,LED Display, ANT(DVB-T/T2)
Heat SinkYES

√Hardware Features:
Rear panelUSB 2.0YES
T2 ANT INFor DVB-T/T2 signal input
COAXIALFor Coaxial output for other audio decoder device
HDMI19 PIN Female HDMI 1.3
AC-INAC 100~250V,50Hz/60Hz
RF OUTYES
SCARTSCART

√Software General Features(DVB-T/T2):
MPEGMPEG-2 SD, MPEG-2 HD, H.265/MPEG-4 SD, H.265/MPEG-4 HD
PAL/NTSCAutomatic PAL/NTSC conversion
Channels NumberFTA channels TV and Radio programs
Favorites8 different favorite groups selection
OSD LanguageOSD Language for options:English,French,German,Italian
Spanish ,Swedish,Portuguese ,Finland,Holland,Turkish,Czech,Greece,Denish,Thai,Arabic
EPGFully support to 7 days Electronic Program Guide(EPG)
PIGPicture in Graphics(PIG) support
Color OSD256 color/8bit On Screen Display
NIT SearchUser can set NIT Search On/Off when execute DVBT2 Search
DiSEqCDiSEqC1.0/1.1/1.2/USALS Motor fully support, 13/18V, 0/22K, 0/12V LNB control
Channel EditVarious channel editing functions(favorite, moving, locking, renaming, deleting and sorting)
Parental ControlParental control for channels
Soft UpgradeSoftware upgrades through USB port, Support OTA.
Timer25 Timer Reservations, automatically switch to a specific channel
SubtitleSubtitle support DVB EN300743 and EBU
TeletextTeletext support DVB ETS300472 by VBI and OSD
HDMI Interface480p_60;480i_30;576i_25; 576p_50; 720p_60;720p_50; 1080i_25;1080p_60;1080p_50
Multimedia SupportTS/MPG/MKV/AVI/ASF/FLV/MP4/WMA/WMV/VOB/MOV/DAT/SRT/SUB/BMP/
JPG/JPEG/GIF/PNG/TIF/MP3/M4A files

Electric Performance:
1. Main Chip SetsCPU frequency608MHz
Flash Memory64Mbit/8Mbyte SPI FLASH
DDR Memory512Mbit
2.  DVB-T/T2 TunerTuner TypeR836
Frequency RangeVHF174~230MHz    UHF 470~862MHz
Input Impedance75Ω
Polarization22KHz±0.4KHz(0.6V±0.2V)tone, Overload Protection
Input Level RangeMin -78dbm max -20dbm(64QAM,8K 1/8,7/8)
Loop-ThroughYES
3.  DVB-T/T2 TunerTuner TypeMXL608
Frequency Range174MHZ-860MHZ
Input Impedance75Ω
Input Level RangeMin -78dbm max -20dbm(64QAM,8K 1/8,7/8)
4.  Video DecoderVideo DecodeMPEG-2 ISO/IEC 13818-2 MP@ML, H.264(MPEG4 part 10) main and high profile level 4.1/MPEG-2 MP@HL
Aspect Ratio4:3,16:9
Video Resolution1920×1080,1280×720,720×480
5.  Audio DecodeAudio DecodeMPEG-1 layerI/II,PCM down mix,IEC958 SPDIF,Dolby 5.1 channel,Dolby down mix 2 channel,Dolby Prologic2 (Optional)
Sound ModeLEFT/RIGHT/STEREO/MONO
Sampling Frequency32KHz,44.1KHz,48KHz
6.  AV OutputVideo BandwidthSD:5.0MHz(-3dB),HD:30MHz(-3dB)
Video Impedance75Ω
Video Voltage Level1.0Vp-p
Audio Freq. Range20~20KHz
Audio Impedance600Ω
Audio Voltage Level2Vrms(5.6Vp-p)
7.  EnvironmentInput VoltageAC 100~250V,50Hz/60Hz
ConsumptionMax 8W
Standby<1W
Temperature0~40ºC
Humidity<95%
