Product Description
| Features | |
| 1.MPEG4 H.264 HD ATSC STB | Fully ATSC compliant for North America with NTIA cert. |
| 2.Fully ATSC compliant, support full HD 1080p | Photo: JPEG, BMP, PNG |
| 3.Support SD/HD MPEG2 and MPEG4 AVC H.264 | ATSC Terrestrial broadcast channels 2-69 |
| 4.Auto and manually scan all available TV and radio channels | Audio: WMA, MP3, AAC (.wma, .mp3, .m4a) |
| 5.HDMI, coaxial output, L/R audio | HDMI for multimedia play, standard and high definition output |
| 6.Multi-language subtitle output supported | Video: MPEG1, MPEG2, MPEG4, H264 |
| 7.Powerful and highly effective 7-day EPG function | Motion JPEG (.avi,.mpg,.dat,.vob,.div,.mov,.mkv,.mjpeg,.ts,.trp) |
| 8.PVR, timeshift, software upgrade via USB 2.0,Parental lock | Aspect ratio 16:9 and 4:3 |
| 9.USB media playback | JPEG/Audio combo playback |
| 10.Four Digits LED Display | HDMI, Coaxial, YPbPr/YUV, RCA output |
| Demultiplexer | Multi-language OSD & Subtitles (English/French/Spanish) |
| ATSC Terrestrial tuner | Support EPG, display Present/Next TV program |
| Standard ISO/IEC 13818-1; ARIB STB-B10 | Demodulation: |
| RF input frequency: 54-803MHz | EIA 608 Closed Caption |
| Input max. bit stream rate: 36Mbps (serial) | ATSC NTIA Standard, 8VSB |
| Bandwith: 6MHz/ 9Mbps (parallel) | QPSK, 64QAM, 256QAM |
| Input level: -83 - -5dBm | PVR ready function via USB 2.0,Timeshift function |
| RF 3/4CH and loop through functionDecoding | FEC: 1/2, 2/3, 3/4, 4/5,5/6, |
| Hardware Interface | NTSC Loop Through supported |
| MPEG transport stream and A/V decoding | Guard Interval: 1/4,1/8,1/16,1/32,1/128 |
| Front Panel | Universal remote control |
| Video decoder: ATSC A/72 MPEG2/4 H.264 SD&HD | FFT Mode: 2K, 8K, 32K |
| USB: Firmware upgrade, PVR & Multimedia playback | ATSC formats |
| LED display (Option) | |
| Packing : | Video resolution: 720X480 NTSC/HDMI 1080P |
| packing : 1 Color Box | Audio standard: ISO/IEC 14.496-3 |
| Color box :198*155*58mm | Rear Panel |
| Qty per export carton : 20pcs pieces | Audio mode: mono, dual-channel, stereo |
| Meas. per export carton : 41*31*33cm | HDMI 1.3: 576i, 576p, 720p and 1080i,1080P |
| One Color box include: | Loop through output: IEC-type, connector, |
| 1* AV Cable 1* User Manual | Ssingle tuner Coaxial digital audio output: RCAx1 |
| 1* ATSC HD Receiver 1* Remote Controler | YPbPr: RCAx3 L/R output: RCA x2 CVB |
